‧ 3 3/4 Display (3999)
‧ Input Sensor: J, K, T, E, S, R
‧ Selectable: ℃ or ℉ Display
‧ DIN Size 96×48mm.
‧ Data Holding is Available (option).
Display……………………….3 3/4 (3999) 0.56〞(14.2mm), Red LED
Accuracy………………………………………………. J.K.T.E ±0.25% F.S.
S.R±0.4% F.S.
Conversion rate (about)………………………………………………… 2/sec.
Over input indication…………………………………………………. “0000”
Operating temp. ……………………………………………………….. 0～60℃
Storage temp. ……………………………………………………….. -10～70℃
Sensor power supply …………………………….. DC 12V ±10% 30mA
Temp. coefficient ……..≦100PPM/℃(≦60PPM/℃, 25℃±10℃)
Max. relative humidity ……………………………………………………. 95%
Dielectric strength ……………… AC 2 KV/1 min. (input/power/case)
Surge test …………………………………….4 KV/1.2×50μs, IEC 255-4
Aux. power …………………………. AC 115V/230V ±10%, 50/60 Hz
DC 24V, 48V, 110V, ±20% (option)
Power consumption …………………………………. AC 3.5VA, DC 3W
Weight (about) …………………………………………………………….. 360g
