SPD-3606 375W DUAL RANGE D.C. POWER SUPPLY 双组输出直流電源

SPD-3606 375W DUAL RANGE D.C. POWER SUPPLY

双组输出直流電源

FEATURES

Three Independent, Isolated Output

CH1/CH2 : Dual Range Output of 30V/

6A or 60V/3A to Cover Wide Application

CH3 Adjustable Output : 0.1~5V/3A

High Efficiency Power Conversion (Up to

25% Then Traditional Power Supply)

Remote Control Output On/Off

OVP to Protect the DUT

OTP to Protect SPD-3606 and Reduce the

Repair Rate

Automatically Switching AC 115V/230V

Source

Fully Safety Design: Reverse Polarity, CH3

Overload Protection, Safe Output Setting ,

CC/CV Mode

High Power Density: Compact Size, Light

Weight

Low Fan Acoustic Noise with Fan Speed

Control Circuit
