Fluke 718 Series Pressure Calibrators

The complete solution to pressure calibration

The Fluke 718 pressure calibrator family (includes 4 models) provide a total pressure calibration solution for transmitters, gauges and switches. This compact pressure calibration solution is about a third of the size of comparable instruments and weighs just one kilogram (two pounds). The unique easy to clean pump helps protect the pump from damage and provides the ability to service the pump without disassembly, even in the field.

——————————————————————————————————————————————————————————–

Pressure Source and Milliamp Measurement to calibrate and maintain almost any pressure device

Integrated pump is easily cleaned when accidently exposed to fluids that reduces cost of ownership and repairs and enables servicing the pump in the field

Error % calculation for quicker pass/fail decision making in the field

Best in class mA accuracy of 0.015 % for better measurement confidence and workload coverage

Min/Max/Hold to capture changing measurements

Switch test feature for quicker and more accurate pressure switch testing

New 1 and 300 PSI pressure ranges mean fewer extra tools required

1, 30, 100 & 300 PSI ranges now available
